Truck mixer Regular (R)
Truck mixer Regular (R) - Image 2
Truck mixer Regular (R) - Image 3
Truck mixer Regular (R) - Image 4
Truck mixer Regular (R) - Image 5
Truck mixer Regular (R) - Image 6
Truck mixer Regular (R) - Image 7

Truck mixer Regular (R)

Call for price

Load volume
15m³

Robust Steel
S355JR

Geometric volume
24.390 l
Request a Quote
Categories: , , Brand:

Features

ALEX EQUIPMENT COMPANY

Rich product models

The overall design and construction are characterised by their robustness and durability under the toughest operating conditions, with the stiffened and extremely solid frame construction at the heart. The centre of gravity is extremely low and, in combination with an optimised load distribution, offers you increased safety at various working phases of filling, transport and unloading. Solid and robust machine construction for your operation!

Technical data

ALEX EQUIPMENT COMPANY

EM4R - 4M³

Capacity nominal 4 m³
Geometric volume 8.430 l
Water tank volume 4.500 l
Tank inclination 15.0°
Length in mm 3,491 mm
Width in mm 2,300 mm
Height in mm 2,302 mm
Total weight in kg 3,300 kg

EM7R - 7M³

Capacity nominal 7 m³
Geometric volume 12.000 l
Water tank volume 7.310 l
Tank inclination 13.6°
Length in mm 6.046 mm
Width in mm 2,300 mm
Height in mm 2,630 mm
Total weight in kg 3,450 kg

EM8R - 8M³

Capacity nominal 8 m³
Geometric volume 14.220 l
Water tank volume 8.979 l
Tank inclination 13.2°
Length in mm 6,383 mm
Width in mm 2,300 mm
Height in mm 2,695 mm
Total weight in kg 3,715 kg

EM9R - 9M³

Capacity nominal 9 m³
Geometric volume 16.110 l
Water tank volume 10.076 l
Tank inclination 11.6°
Length in mm 6,785 mm
Width in mm 2,300 mm
Height in mm 2,693 mm
Total weight in kg 3,820 kg

EM10R - 10M³

Capacity nominal 10 m³
Geometric volume 17.361 l
Water tank volume 11.121 l
Tank inclination 11.3°
Length in mm 7,080 mm
Width in mm 2,300 mm
Height in mm 2,700 mm
Total weight in kg 3,965 kg

EM12R - 12M³

Capacity nominal 12 m³
Geometric volume 19.420 l
Water tank volume 15.200 l
Tank inclination 10.5°
Length in mm 7,545 mm
Width in mm 2,300 mm
Height in mm 2,765 mm
Total weight in kg 4,725 kg

EM15R - 15M³

Capacity nominal 15 m³
Geometric volume 24.390 l
Water tank volume 15.200 l
Tank inclination 9.3°
Length in mm 7,545 mm
Width in mm 2,300 mm
Height in mm 2,569 mm
Total weight in kg 5,395 kg
