Technical information
ALEX EQUIPMENT COMPANY
Dimensions
Specification
| Description | mm(Ft-inch) | |
| O | Loader Hinge Pin Height | 3610 (11′ – 10″) |
| M | Bottom Opening Dump Height | 2960 (9′ – 8″) |
| C | Reach at Ground (Carry Position) | 1600 (5′ – 3″) |
| U | Roll Back at Ground | 50° |
| T | Depth of the Bucket | 80 (0′ – 3″) |
Engine
| Engine | PERKINS 1104D-44TA, EU NRMM 97/68/EC, EURO III A, |
| No of cylinder: | 4 |
| Gross Power: | 74.5KW (100HP) @2200 RPM |
| Torque | 410 NM @ 1400 RPM |
Transmission
ZF Power Shift Transmission with integral torque convertor.
The pedals layout and conventional 4 pattern gear lever with transmission disconnect switch adds to the overall ease of operation.On the move gear changes are possbile.
Option: SMART HTS offers state of the art open loop Hydrostatic drive(Patent pending).
Axles
Rear: Drive axle rigidly mounted, incorporates Max-trac torque proportioning differential, driven by short propshaft from gear box.
Front: Steer axle, centrally pivoted with oscillation angle ±16°.
Steering
Full power, front wheel hydraulic power steering with manual capability in the event of engine or hydraullic power failure.
Hydraulic supply from pump via priority valve. Working pressure psi (240 bar)
Drive
4 WD available
Electricals
180 Ampere-hour 12 volts battery system with alternator and full road lighting.
Tyres
Front: 2WD: 9.00X16 – I6PR, 4WD: 12.5/80X18 -12PR
Rear: 2WD&4WD :16.9X28 -12PR(STD INDUSTRIAL TYRE) : 14.00X25-20PR(HEAVY DUTY TYRE)
Turning Circle
Inner wheels bracked
A* Outside loader bucket 8.8 m
B Outside Wheels 6.3 m
Inner wheels not bracked
A* Outside loader bucket 11.6 m
B Outside Wheels 8.9 m
Speed
| Forward Km/hr | Reverse Km/hr |
| 40 Km/hr | 9.3 Km/hr |
Hydraulics
SMART technology hydraulics : 3335 psi (230 bar).
Pump flow : 145 LPM@ 2200RPM.
Pump Type : Gear Pump
Weight
8200 Kgs with Standard GP bucket option.
Service Capacities
| System | Service | |
| Hydraulic Tank | 120 Ltr | 100 Ltr |
| Fuel Tank | 115 Ltr | – |
| Engine Coolant | 17 Ltr | 15 Ltr |
| Engine Oil | 10 Ltr | 10 Ltr |
| Transmission | 19.5 Ltr | 16 Ltr |
| Rear axle | 17 Ltr | 17 Ltr |
| 4WD Front Axle | 8 Ltr | 8 Ltr |
CAB
- Front Curved cab glasses provide excellent visibility.
- Excellent operator safety. Conforms to ROPS and FOPS standards .
- Plenty of legroom minimises fatigue and allows the operator to work un-interrupted for long hours.
- A fully adjustable seat combined with ergonomically positioned controls and soft touch steering wheel.
- Cab provides easy ‘walk through’ two door access. Other features include seat belt, large convex rear view mirror, interior light, front screen wiper, front and rear horn, hazard warning system, tool box and helper seat.
- Instrumentation panel is positioned on the right hand side includes engine speed, engine hours, fuel level and water temperature.
- Audible and visual fault warning system for alternator charge, coolant temperature, engine oil pressure, blocked air filter, transmission oil temperature and hand-brake on.
Options
Excavator Buckets
Capacities
0.27 cu.m (standard)
Options
– 0.12 cu.m
0.17 cu.m
0.21 cu.m
Ditch Cleaning Bucket
Taper Ditching Bucket
Square hole bucket
Rock Breaker
Ripper Tooth
Trench Bucket
Loader booster bucket with 12ft-11 inch dump height
6 in 1 Bucket
4 wheel drive
